KSP6-NV5-SCO-K32L

A complete alarm system package centred on the Spectra SP6000 control panel. This kit includes the K32L LED keypad, NV5 PIR motion detectors, tamper-protected enclosure, backup battery, power supply, and internal/external sirens — providing a professional-grade security solution for residential and small business installations.

🔑 Key Features

• Spectra SP6000 panel with 8 zones expandable to 32

• Includes K32L LED keypad with illuminated zone display

• Supplied with NV5 PIR detectors for reliable motion detection

• Equipped with internal piezo siren and external combo siren/strobe

• Integrated bell relay and 4 programmable outputs (PGM)

• Backup battery and regulated power supply included

• Sturdy tamper-protected metal enclosure for secure installation

🛠 Technical Specifications

• Control Panel: Spectra SP6000 (8 zones expandable to 32)

• Keypad: K32L LED keypad with zone display indicators

• Detectors: 2 × NV5 passive infrared motion detectors

• Housing: 11x11x3 metal box with tamper switch and bracket

• Battery: 12VDC, 7Ah AGM sealed rechargeable

• Power Supply: 16VAC, 1.5A plug pack (3-wire)

• Audible Alerts: WP08 piezo siren (105dB), SCO3/CO combo siren strobe (flat cover, EOLR)

• Connectivity: Telephone lead with 606 socket and 2M cord

• Documentation: MG/SP Series user manual (English)

📦 Package Includes

• 1 × Spectra SP6000 control panel (StayD, 4 PGM, no built-in box)

• 1 × K32L LED keypad

• 1 × Metal box 11x11x3 (2780000033)

• 1 × Tamper switch (2502302000)

• 1 × Tamper bracket 3INCH (2781030000)

• 1 × 12VDC/7Ah AGM battery (SA12V7)

• 1 × 16VAC/1.5A plug pack power supply (16VAC1500MPS/6)

• 1 × WP08 top hat piezo siren, 90mA, 105dB

• 1 × SCO3/CO combo siren strobe with flat cover (EOLR)

• 2 × NV5 PIR motion detectors

• 1 × Telephone lead with 606 socket and 2M cord (LC0280)

• 1 × MG/SP Series user manual (MSPU)

🎯 Best Used For

• Residential systems needing zone display keypad and PIR detection

• Small to medium commercial premises requiring reliable alarm coverage

• Installers seeking a complete pre-bundled kit ready for immediate deployment

• Security systems expandable to 32 zones for scalable growth
