KSP65-476-CSS-NK

A reliable alarm system package built around the Spectra SP65 control panel. This kit includes a 476 passive infrared detector, backup battery, tamper-protected enclosure, regulated power supply, and both internal and external sirens — providing a strong foundation for residential and small business security installations.

🔑 Key Features

• Spectra SP65 control panel with 8 zones expandable to 32

• Includes 476 PIR detector for accurate motion detection

• Integrated bell relay and 4 programmable outputs (PGM)

• Supplied with internal piezo siren and external combo siren/strobe

• Rechargeable sealed backup battery and power supply included

• Professional-grade tamper-protected metal enclosure

🛠 Technical Specifications

• Control Panel: Spectra SP65 (8 zones expandable to 32)

• Detector: 1 × 476 passive infrared motion detector

• Housing: 11x11x3 metal enclosure with tamper switch and bracket

• Battery: 12VDC, 7Ah AGM sealed rechargeable

• Power Supply: 16VAC, 1.5A plug pack (3-wire)

• Audible Alerts: WP08 top hat piezo siren (105dB), WP16 combo siren strobe (flat cover, EOLR)

• Connectivity: Telephone lead with 606 socket and 2M cord

• Documentation: MG/SP Series user manual (English)

📦 Package Includes

• 1 × Spectra SP65 control panel (StayD, 4 PGM, no built-in box)

• 2 × 476 PIR motion detector

• 1 × Metal box 11x11x3 (2780000033)

• 1 × Tamper switch (2502302000)

• 1 × Tamper bracket 3INCH (2781030000)

• 1 × 12VDC/7Ah AGM battery (SA12V7)

• 1 × 16VAC/1.5A plug pack power supply (16VAC1500MPS/6)

• 1 × WP08 top hat piezo siren, 90mA, 105dB

• 1 × WP16 combo siren strobe with flat cover (EOLR)

• 1 × MG/SP Series user manual (MSPU)

🎯 Best Used For

• Residential installations needing a cost-effective PIR-based alarm system

• Small commercial projects requiring reliable detection and siren alerts

• Installers seeking a foundation kit with sirens and backup power included

• Security systems expandable to 32 zones
