KSP65-ACB1-NK

A streamlined alarm system package centred on the Spectra SP65 control panel. This kit includes the control panel, tamper-protected metal enclosure, backup battery, regulated power supply, and internal/external sirens — providing a solid foundation for installers to add their preferred keypad.

🔑 Key Features

• Spectra SP65 control panel with 8 zones expandable to 32

• Delivered without keypad for flexible configuration

• Integrated bell relay and 4 programmable outputs (PGM)

• Tamper-protected enclosure with backup battery and power supply

• Provides a ready-to-build kit that can be tailored to site requirements

🛠 Technical Specifications

• Control Panel: Spectra SP65 (8 zones expandable to 32)

• Enclosure: 11x11x3 metal box with tamper switch and bracket

• Battery: 12VDC, 7Ah AGM sealed rechargeable

• Power Supply: 16VAC, 1.5A plug pack (3-wire)

• Documentation: MG/SP Series user manual (English)

📦 Package Includes

• 1 × Spectra SP65 control panel (StayD, 4 PGM, no built-in box)

• 1 × Metal box 11x11x3 (2780000033)

• 1 × Tamper switch (2502302000)

• 1 × Tamper bracket 3INCH (2781030000)

• 1 × 12VDC/7Ah AGM battery (SA12V7)

• 1 × 16VAC/1.5A plug pack power supply (16VAC1500MPS/6)

• 1 × MG/SP Series user manual (MSPU)

🎯 Best Used For

• Installers who prefer to choose their own keypad (LED, LCD, or touchscreen)

• Residential installations needing a scalable base kit

• Small commercial projects requiring siren and strobe alerts

• Security systems expandable to 32 zones
