KSP65-NV5X3-CSS-K10V

A complete alarm system package centred on the Spectra SP65 control panel. This kit includes the K10V LED keypad, NV5 PIR motion detectors, backup battery, tamper-protected enclosure, power supply, and sirens — providing a reliable, scalable, and cost-effective solution for residential and small business security.

🔑 Key Features

• Spectra SP65 panel with 8 zones expandable to 32

• Includes K10V LED keypad for simple, intuitive operation

• Supplied with 3 × NV5 PIR detectors for accurate motion detection

• Integrated bell relay and 4 programmable outputs (PGM)

• Backup battery and regulated power supply included

• Internal piezo and external combo siren/strobe for strong alerts

• Durable tamper-protected metal enclosure

🛠 Technical Specifications

• Control Panel: Spectra SP65 (8 zones expandable to 32)

• Keypad: K10V LED keypad with status indicators

• Detectors: 3 × NV5 passive infrared motion detectors

• Housing: 11x11x3 metal box with tamper switch and bracket

• Battery: 12VDC, 7Ah AGM sealed rechargeable

• Power Supply: 16VAC, 1.5A plug pack (3-wire)

• Audible Alerts: WP08 piezo siren (105dB), WP16 combo siren strobe (flat cover, EOLR)

• Connectivity: Telephone lead with 606 socket and 2M cord

• Documentation: MG/SP Series user manual (English)

📦 Package Includes

• 1 × Spectra SP65 control panel (StayD, 4 PGM, no built-in box)

• 1 × K10V LED keypad

• 1 × Metal box 11x11x3 (2780000033)

• 1 × Tamper switch (2502302000)

• 1 × Tamper bracket 3INCH (2781030000)

• 1 × 12VDC/7Ah AGM battery (SA12V7)

• 1 × 16VAC/1.5A plug pack power supply (16VAC1500MPS/6)

• 1 × WP08 top hat piezo siren, 90mA, 105dB

• 1 × WP16 combo siren strobe with flat cover (EOLR)

• 3 × NV5 PIR motion detectors

• 1 × MG/SP Series user manual (MSPU)

🎯 Best Used For

• Residential installations needing simple keypad control with PIR detection

• Small commercial sites requiring reliable intrusion detection

• Installers seeking a cost-effective pre-bundled kit ready for deployment

• Security systems expandable to 32 zones for future growth
