NVR301-08B-P8-IQ
NVR301-08B-P8-IQ – 8-Channel Smart NVR with 8-Port PoE Switch
A powerful 8-channel network video recorder with built-in 8-port PoE switch, ideal for medium-sized surveillance systems. Supports high-resolution IP cameras, smart analytics, and remote monitoring—all in a compact, fanless design.
📌 Key Features
8 IP camera inputs with real-time recording
Built-in 8-port PoE switch for simplified installation
Supports up to 8MP resolution per channel
Smart analytics supported when paired with AI-enabled cameras
Simultaneous HDMI and VGA output for flexible monitoring
Smart search, motion playback, and video tagging
Pre-configuration friendly for plug-and-play setup
Silent fanless operation
⚙️ Technical Specifications
Video Input: 8 IP channels
PoE Ports: 8 × 100Mbps (IEEE 802.3af/at compliant)
Max Resolution: 8MP per channel
Recording Bandwidth: 80Mbps incoming
Decoding Capability: 2 × 8MP, 4 × 4MP, or 8 × 1080p
Video Output: 1 HDMI (up to 4K), 1 VGA
Compression: Ultra 265, H.265, H.264
Storage: 1 × SATA HDD bay (supports up to 10TB)
USB Ports: 2 × USB 2.0
Smart Features: Motion detection, AI filtering (human/vehicle), smart playback
Remote Access: CMS, web browser, and mobile app
Power Supply: DC 48V, PoE power budget approx. 96W
Power Consumption: ≤10W (excluding HDD and PoE output)
Operating Temp: -10°C to 55°C
Dimensions: 300 × 248 × 47MM
Weight: Approx. 1.7KG (without HDD)
🎯 Best Used For
Medium business or multi-camera retail setups
Sites requiring simple plug-and-play PoE camera connections
Projects with up to 8 IP cameras using smart video features
Systems needing future-ready AI camera integration
Quiet environments needing fanless, compact NVR units
Documents
Specifications
Brand | UniView |
