The Ubiquiti UniFi Dream Machine Pro Max is a next-generation enterprise gateway designed for organisations demanding extreme performance, high-capacity routing, and unified network, security, and surveillance management. Built with enhanced processing power, improved throughput, and 10G connectivity across WAN and LAN, the UDM Pro Max is engineered to support large networks, multi-site deployments, and environments where uptime, speed, and advanced security are mission-critical.
🔑 Key Features
High-performance router, firewall, and UniFi OS console in a single 1U appliance
Substantially improved IDS/IPS and threat management throughput compared to UDM Pro
Integrated UniFi Network, Protect, Access, Talk, and Connect applications
Dual WAN with 10G SFP+ and 2.5G RJ45 for high-speed failover and load balancing
8-port Gigabit switch with 10G SFP+ LAN uplink for flexible network expansion
🛠Technical Specifications
Model: UDM Pro Max
Voltage / Power: 100–240 V AC internal PSU; maximum power consumption approximately 40 W
Routing Performance: Multi-gigabit routing with significantly enhanced IDS/IPS throughput
Storage: 3.5" HDD bay for UniFi Protect recordings (HDD sold separately)
Connections:
1 × 10G SFP+ WAN
1 × 2.5G RJ45 WAN
8 × 1G RJ45 LAN
1 × 10G SFP+ LAN
1 × RJ45 console port
Dimensions: 442.4 × 43.7 × 285.6 MM
Material / Finish: Metal chassis with front touch display for system status and controls
Mounting Style: Standard 19" rackmount (rack ears included)
Environment: Operating temperature 0 °C to 40 °C; humidity 10–90% non-condensing
🎯 Best Used For
Ideal for large businesses, multi-tenant buildings, enterprise campuses, hotels, managed service environments, and organisations that require extremely high throughput, advanced threat protection, large-scale UniFi Protect deployments, and unified management across all UniFi platforms.
✅ Complementary Products (Same Brand)
UniFi Enterprise Access Points such as U6 Enterprise or U7 Pro Max for high-density WiFi
UniFi PoE Switches including USW Enterprise and Aggregation models
UniFi Protect Cameras such as G5 Pro, G5 Turret, and G4 PTZ for large surveillance systems
UniFi Access door controllers and readers for integrated facility security
UniFi 10G SFP+ modules and DAC cables for high-speed uplinks
The UDM Pro Max is built as the performance-driven core of a professional UniFi deployment, providing the power, scalability, and security required for modern business networks.
