The Ubiquiti UniFi Switch Pro 24 is a powerful, second-generation Layer 3 managed switch engineered for scalable business and enterprise networks. With 24 Gigabit Ethernet ports and high-speed 10G SFP+ uplinks, it delivers advanced switching, routing, and reliability as a core or distribution switch within the UniFi ecosystem.
🔑 Key Features
24 Gigabit Ethernet RJ45 ports for high-density wired connectivity
2 × 10G SFP+ ports for high-speed fibre uplinks and aggregation
Layer 3 switching with inter-VLAN routing and static routing support
UniFi Network application management with advanced monitoring and analytics
Rackmount-ready design built for continuous, high-performance operation
🛠Technical Specifications
Model: USW-PRO-24
Voltage / Power: 100–240 V AC internal power supply
PoE Output: Not supported (non-PoE model)
Switching Capacity: 88 Gbps
Forwarding Rate: 65.5 Mpps
Connections:
Dimensions: 442.4 × 285.6 × 43.7 MM (1U rackmount)
Weight: Approximately 4.4 kg
Material / Finish: Metal chassis with active cooling
Mounting Style: Standard 19IN rackmount (rack ears included)
Environment: Indoor use; operating temperature 0 °C to 40 °C; humidity 10–90% non-condensing
🎯 Best Used For
Ideal for enterprise offices, campuses, warehouses, and multi-floor buildings requiring advanced Layer 3 switching, high port density, and 10G backbone connectivity for scalable and resilient network design.
✅ Complementary Products (Same Brand)
UniFi gateways such as UDM-Pro, UDM-SE, or UDM Pro Max for advanced routing and security
UniFi Aggregation switches for 10G backbone and switch stacking
UniFi WiFi access points such as U6 Pro, U6 Enterprise, or U7 Pro Max for high-density wireless coverage
UniFi Protect cameras for integrated surveillance deployments
UniFi Redundant Power System (USP-RPS) for enhanced power resilience
UniFi SFP+ modules or DAC cables for high-speed fibre uplinks
UniFi rack accessories and cable management for clean, professional installations
The UniFi Switch Pro 24 serves as a reliable, high-performance foundation for enterprise UniFi networks, supporting advanced routing, high-speed uplinks, and seamless scalability across wired and wireless infrastructure.
