The Ubiquiti UniFi Switch Pro 48 is a second-generation, enterprise-grade managed switch built to deliver high-density Gigabit connectivity with advanced Layer 2 and Layer 3 capabilities. Designed for scalability and reliability, it features 10G SFP+ uplinks and an integrated touch display, making it a strong access or distribution switch for modern UniFi networks.
🔑 Key Features
48 Gigabit Ethernet RJ45 ports for high-density wired connectivity
4 × 10G SFP+ ports for high-speed fibre uplinks and aggregation
Advanced Layer 2 and Layer 3 switching including inter-VLAN routing and static routes
UniFi Network application management with detailed monitoring and analytics
Integrated front touch display for real-time status and diagnostics
🛠Technical Specifications
Model: USW-PRO-48 (Gen2)
Voltage / Power: 100–240 V AC internal power supply
PoE Output: Not supported (non-PoE model)
Switching Capacity: 176 Gbps
Forwarding Rate: 130.9 Mpps
Connections:
Dimensions: 442.4 × 285.6 × 43.7 MM (1U rackmount)
Weight: Approximately 5.3 kg
Material / Finish: Metal chassis with active cooling and front touch display
Mounting Style: Standard 19IN rackmount (rack ears included)
Environment: Indoor use; operating temperature 0 °C to 40 °C; humidity 10–90% non-condensing
🎯 Best Used For
Ideal for enterprise offices, campuses, warehouses, and multi-floor buildings that require high port density, advanced Layer 3 switching, and fast 10G backbone connectivity to support scalable and resilient network architectures.
✅ Complementary Products (Same Brand)
UniFi gateways such as UDM-Pro, UDM-SE, or UDM Pro Max for advanced routing and security
UniFi Aggregation switches for 10G core and backbone expansion
UniFi WiFi access points such as U6 Pro, U6 Enterprise, or U7 Pro Max for high-density wireless coverage
UniFi Protect cameras for integrated surveillance deployments
UniFi Redundant Power System (USP-RPS) for enhanced power resilience
UniFi SFP+ modules or DAC cables for high-speed fibre uplinks
UniFi rack systems and cable management accessories for clean, professional installations
The UniFi Switch Pro 48 delivers enterprise-class performance, scalability, and control, making it a reliable foundation for large-scale UniFi network deployments.
